Description
Output Voltage
24 V
Output Current
DUAL OUTPUT
Battery Chemistry
Lead Acid & NiCd
Charging Mode
Float & Boost
Part Number
PIPL-2435X2BCD
Battery Type
Lead Acid/VRLA SMF Battery Charger
Cooling
Forced Air
Protection
Short Circuit Protect, Overtemperature Protect, Overvoltage Protect, Overcurrent Protect
Brand
Powertron
Mounting Type
Floor Mount
Warranty
1 Year
Input Frequency
50Hz
Battery Voltage
24V
Metering
O/P Voltage & Current For Charging & load
Efficiency
Greater Than 85%
Power Factor Correction
0.99
Operating Temperature
Max. 55 Degree C
Mode of Operation
Auto and Manual with Selector Switch
Enclosure IP Grade
IP 42
Enclosure Shed
RAL7032
Cooling Type
Conventional Fan Cooled
Switch Gears
Input MCB, Charging MCB
Input Voltage
AC 415V
Phase
3Phase
Country of Origin
Made in India
Float Charging Voltage
27V
Boost Charging Voltage
28.8V
Charger Current Capacity
35Amp
Float Charging Current
10Amp.
Boost Charging Current
25Amp.
Charger Type
Dual FCBC
Number of Wire
4Wire
Features:
Wide Input Supply Range
Auto Manual Selection Switch (Optional)
Reverse Polarity Protection
Compact
High Reliability
Digital Voltmeter & Ammeter (Optional)
Input, Output MCB (Optional)
Fast Charging
Suitable for VRLA / SMF / NiMH / NiCD / LiON etc.
