Description
Output Voltage
24 V
Output Current
20 A
Power Rating
500 W
Battery Type
LEAD ACID
Battery Capacity
200AH
Charging Technology
SMPS
Mounting Type
Panel Mount
Application
Telecom, Medical
Input Voltage
230 V AC
Part Number
PIPL-2420BC
Number Of Outputs
1 Output
Brand
Powertron
Protection
Over Voltage, Over Charge
Max. Working Temperature
55 Degree C
Working Humidity
90% Rh Non Condensing
Enclosure Protection
IP-20
Cooling
Forced Cooling
Dimension
235 x 190 x 100 mm (L x W x H)
Weight
2.8Kg
Battery Voltage
DC 24V
Float Voltage
DC 27.0V
Boost Voltage
DC 28.8V
Country of Origin
Made in India
Rated Current
20A
Rated Power
600W
Ripple & Noise (Max)
<1% Of Rated Voltage
Line Regulation
<+/-1%
Load Regulation
<+/-1%
Voltage Range
AC 270V
Frequency Range
50Hz
Efficiency
>85%
Min. Working Temperature
-5 Degree C
Features:
Wide Input Supply Range
Auto Manual Selection Switch (Optional)
Reverse Polarity Protection
Compact Design
High Reliability
Digital Voltmeter & Ammeter (Optional)
Input,Output MCB (Optional)
Fast Charging
Suitable for VRLA / SMF / NiMH / NiCD / LiON etc.
