Description
Input Voltage
90V TO 270VAC
Current
3 A
Color
Black
Usage/Application
Industrial Automation
Material
ABS Plastic
Converter Type
Buck
Power
40 W
Adapter Type
DC ADAPTER
Isolation
Isolated
Connector Type
CUSTOMIZED
Pin type
3
Model No
PIPL-1203ADP
Application
Industrial, Telecom, Automotive
Brand
Powertron
Model Name/Number
PIPL-15ADP
Efficiency
Better than 85%
OVERLOAD
Above 105%Rated Output Power
Output Voltage
12V DC
OVER VOLTAGE
125%-150% Rated Output Voltage
Output Current
1A
WORKING TEMP.
(-5DegC To 55DegC.)
WORKING HUMIDITY
20 To 90% RHNon Condensing
STORAGE TEMP./ HUMIDITY
(-10 To 85DegC 10 To 95%RH)
VIBRATION
(-10 To 500 Hz,2G,20min/Sweep,Period-1Hr,Each along X,Y,Z axes
SAFETY STANDARD
Designed To Meet UL60950-1
WITH STAND VOLTAGE
I/P-O/P:2KVDC,I/P-Earth:2KVDC
ISOLATION RESISTANCE
I/P-O/P,I/P-Earth, O/P-Earth:100MOhms/500VDC
EMI & EMC
Designed To Meet EN55022,EN61000-4-2.
ENCLOSURE PROTECTION
IP-21
COOLING
NATURAL
AC Input Range
100 to 270 VAC
Working Temperature
-15 deg to 65 deg C
Output Ripple and Noise
Less than 1%
Input Frequency
50 Hz
RATED POWER
36W
Country of Origin
Made in India
RIPPLE & NOISE (max)
<1%Of Rated Voltage
VOLTAGE TOLERANCE
Rated Voltage Of +/-1%
LINE REGULATION
<+/-0.5%
LOAD REGULATION
<+/-0.5%
