Description
Max Power
6000 W
Load Type
Customized
Max Voltage
250VDC
Rated Power
25 kW
Max Current
100 A
Voltage Rating
250VDC
Operation Mode
CC CV
Phase
Single Phase
Channel Count
Single Channel
Interface
LAN, Front Panel, RS232, 485, USB, Analog Control
Cooling Type
Air Cooled
Display Type
LCD
Dimension (W x D x H)
427 × 175 × 640 MM
Weight (in KG)
28 KG
FEATURES :
Four Operating Modes: CV, CC, CR, CP
Battery Test Function, Automatic Test Function, Opp Test, Ocp Test Function And Cr-Led Function
Dynamic Mode Up To 10Khz
Voltage Measurement Resolution Up To 0.1Mv / 0.1Ma
Remote Sense
Short Circuit Function
Current Monitoring Function
Power-Off Memory Function
Optional Usb / Rs232 / Rs485 Interface
100 Groups Memory Capacity
