Description
Input Voltage
110VDC
Output Voltage
230VAC (DUAL O/P)
Output Power
1000W (DUAL O/P)
Output Waveform
Pure Sine Wave
Phase
customized
Application
Marine, Vehicle, Railway, UPS, Solar, Telecom, Industrial
Output Frequency
50/60 Hz
Weight
35 Kg
Protection Features
Under Voltage, Overload, Short Circuit, Over Voltage
Brand
Powertron
Voltage Range
110 VDC
Minimum Working Temperature
-5 Degree C
Max. Working Temperature
65 Degree C
Working Humidity
90% Rh Non Condensing
Dimension
19" Rack Mount
Enclosure Protection
IP-20
AC Voltage
230 VAC
Efficiency
>90%
Country of Origin
Made in India
Rated Power
1000W
Cooling
Forced Cooling
Frequency
50Hz
Tolerance Rated Voltage
+/-1%
Features:
Wide input supply range
Protection: Short circuit / Over load / Over voltage
100% Full Load Burn in test
High efficiency, long life and high reliability
Miniature size
