Description
Output Power (W)
1000W
Input Voltage
48 V DC
Output Voltage (VDC)
24V
Output Power
1 kW
Output Voltage
24VDC
Mounting Type
Rack Mount
Application
Railway, Medical, Automotive, Telecom, Industrial, Defence
Current
40AMP
Output Current
40 A
Number of Outputs
Single
Protection Features
Overload, Over Voltage
IP Rating
Not Rated
Features
Parallel Operation
VOLTAGE ADJ.RANGE
FIXED
WORKING HUMIDITY
20 To 90% RH Non Condensing.
ISOLATION
Input& Output Ground are Isolated
LINE REGULATION
<+/-0.5%
VOLTAGE RANGE
40VDC-60VDC
WORKING TEMP.
-5DegC To 75DegC
TOTAL RATED POWER
1000W
EMI & EMC
Designed To Meet EN55022, EN61000-4-2.
LOAD REGULATION
<+/-0.5%
VIBRATION
(-10 To 500 Hz,2G,20min/Sweep,Period-1Hr,Each along X,Y,Z axes.
ENCLOSURE PROTECTION
IP-21
SAFETY STANDARD
Designed To Meet UL60950-1
EFFICIENCY
>85%
RIPPLE & NOISE (max)
<1%Of Rated Voltage
DC VOLTAGE
24VDC
WITH STAND VOLTAGE
I/P-O/P:1.5KVDC,I/P-Earth:1.5KVDC
VOLTAGE TOLERANCE
Rated Voltage Of +/-1%
Country of Origin
Made in India
LED INDICATION FOR EACH
INPUT OK, OUTPUT OK
DIMENSION
490*320*180(MM)
STORAGE TEMP./ HUMIDITY
(-10 To 85DegC 10 To 95%RH)
