Description
Max Power
15 kW
Max Voltage
150 V
Max Current
50AMP
Operation Mode
CUSTOMIZED
Channel Count
Single Channel
Interface
CUSTOMIZED
Model Name/Number
PIPL-15050BDC
Power Supply
7500W
Cooling Type
Air Cooled
Application
Solar Testing, Battery Testing, SMPS Testing, Power Supply Test
Temperature
(-5DegC To 55DegC.)
Data Hold
No
Country of Origin
Made in India
DISCHARGER VOLTAGE
150VDC
CURRENT
50AMP
RATED POWER
7500W
RIPPLE & NOISE (max)
<1% Of Rated Voltage
LINE REGULATION
<+/-1%
LOAD REGULATION
<+/-1%
ENCLOSURE PROTECTION
IP-20
COOLING
FORCED COOLING
FEATURES:
1. Wide input supply range.
2. Built in EMI filter, low ripple noise.
3. Protection: Short circuit / Over load / Over voltage.
4. 100% Full Load Burn in test.
5. High efficiency, long life and high reliability.
6. Miniature size.
