Description
Max Power
2000W
Max Voltage
60VDC
Max Current
30 A
Operation Mode
CV, CC
Channel Count
Single Channel
Interface
CUSTOMIZED
Model Name/Number
PIPL-6030BDC
Power Supply
60VDC
Form Factor
Rack Mount
Cooling Type
Forced Air
Application
SMPS Testing, Battery Testing, Power Supply Test
Display Type
LCD
Operating Temperature
(-5DegC To 55DegC.)
Country of Origin
Made in India
CURRENT
30AMP
RIPPLE & NOISE (max)
<1% Of Rated Voltage
LINE REGULATION
<+/-1%
LOAD REGULATION
<+/-1%
ENCLOSURE PROTECTION
IP-20
COOLING
FORCED COOLING
FEATURES :
1. Wide input supply range.
2. Built in EMI filter, low ripple noise.
3. Protection: Short circuit / Over load / Over voltage.
4. 100% Full Load Burn in test.
5. High efficiency, long life and high reliability.
6. Miniature size.
